Fluting Paper Machine 2200mm vacuum rubber suction roll

Name: Fluting Paper Machine 2200mm vacuum rubber suction roll
Brand: PINGAN
Price: 1 USD

Wholesale Fluting Paper Machine 2200mm vacuum rubber suction roll from china suppliers

Brand Name : PINGAN

Model Number : DIA650x2400MM

Certification : ISO9001:2003

Place of Origin : Henan province, China

MOQ : 1set

Payment Terms : T/T, L/C

Supply Ability : 50sets/month

Delivery Time : 30days

Packaging Details : wooden case

Condition : New

Warranty : 12 month after working

After-sales service provided : engineers are available to supply service abroad.

Weight : 14Tons

Application : paper making machine

Type : suction roll

Product type : rubber roll

Material : cast iron and rubber

Function : remove water from wet paper sheets

Contact Now

Vacuum rubber roll suction roll for fluting paper making machine

Main description

1. There is closed system between vacuum chamber and inner wall of the vacuum rubber suction roll. Suction width is adjustable. Max. suction width is 2200mm, and mini suction width is 1950mm.

2. Roll body: Stainless steel, surface clad rubber. Rubber thickness is 20mm (roll surface drill double helix arranged holes, and holes opening rate is 11.5%)

3. Transmission side shaft: 45# steel, with transmission

4. Operation side shaft: 45# steel

5. Vacuum chamber: cast iron

6. Closed system: incluidng air bube and sealing strips.

7. Adjust system: including worm and worm wheel system

8. Lubrication: grease

Main parameter of paper machine

Working speed	40-150m/min.
Design speed	200m/min.
Balance speed	300m/min.
Paper sheet width	1950mm
Paper sheet tension	0.7-1.6kN/m
Max. linear pressure	100kN/m
